Specifications

 Technique

Rated output

 1.5±10% mV / V

Zero balance

 ±2 % F.S.

Non-linearity

 ≤1 % F.S.

Hysteresis

 0.25 % F.S.

Repeatability

 0.25% F.S.

Temp.effect on output

 0.36 % F.S. / 10°C

Temp.effect on zero

 0.18 % F.S. / 10°C

Input impedance

 350±10Ω

Output impedance

 350±5Ω

Insulation

 ≥5000MΩ/100VDC

Recommended excitation

 5 V

Maximum excitation

 10 V

Compensated temp range

 - 10 ~ 60°C

Operation temp range

 - 20 ~ 80°C

Safe overload

 120% F.S.

Ultimate overload

 200 % F.S.

Cable size

 ?2×3000 mm

Protection class

 IP64

Cable color code

 Input:    Red(+)    Black(-);
 Output: Green(+)  White(-);
