Pressure & Temperature Integrate Transmitter - JQWY

? Pressure Measuring range: 0～110kPa
? Temperature Measuring range: 0°C～50°C
? Power supply: DC 24V (18V～32V)
? Environment temperature: 0°C～50°C
? Pressure Response time: ≤ 50ms
? Temperature Response time: ≤ 2s
? Hysteresis and repeatability: ± 0.2％F.S
? Nonlinear: ± 0.2％F.S

Model Number: JQWY

Quantity:: - +

Inquire Now Add to cart

Mouse over image to zoom

Product Specification

JQWY Pressure & Temperature Integrate Transmitter Introduction
Suitable for all kinds of environment atmospheric pressure and temperature combined measurement.

JQWY Pressure & Temperature Integrate Transmitter Characteristic
? Have good stability for a long time
? Have intelligent digital circuit compensation and wide usage temperature
? Prevent surge voltage and reverse polarity protection
? Have anti-jamming design
? High sensitivity and low temperature drift
? Can match LCD at site

JQWY Pressure & Temperature Integrate Transmitter Parameters

Measuring range	Pressure: 0～110kPa Temperature: 0°C～50°C
Power supply	DC 24V (18V～32V)
Accuracy	Pressure: ± 0.25％ Temperature: ± 1°C
Load capacity	≤ 500Ω
Environment temperature	0°C～50°C
Response time	Pressure ≤ 50ms Temperature ≤ 2s
Hysteresis and repeatability	± 0.2％F.S
Long-term stability	± 0.1％F.S/y
Nonlinear	± 0.2％F.S
Thermal zero drift	± 0.02％F.S/°C
Over load pressure	two times of range
Electrical connection	cable
Measuring medium	air
